I installed gargoyle on GL-MT6000, Internet Connect Via:PPPOE ipv6 dual stack 1Gbps, in the speed test on the wire it does not exceed 500Mbps Download and Uploud 890Mbps, disable Bandwidth Monitor i reach up to 890/908 Mbps download and 880/923 upload
If you’ve got kids or housemates that need to be kept under control by giving them hard download/upload limits or similar Gargoyle is absolutely fantastic. Has functions that no other consumer or prosumer off the shelf units provide. Highly recommended.
Source: Used back in the day to limit my kids on my 30GB limit ADSL connection
I think dual stack PPPoE is giving you some reduction in performance here. I’m surprised, I would have thought the router is capable. I think maybe some process tuning to push processes onto different CPUs (e.g. using irqbalance), but this can also result in poorer results in some circumstances.
For what it is worth, a simple IPoE example using iPerf here showed 901MBit/sec in both directions
With Gargoyle QoS enabled, this dropped to 806MBit/sec.
With QoS on, BWMon Off, 827MBit/sec
Note that 940MBit/sec is really the theoretical maximum due to TCP overheads, and that I have a relatively weak client on the other end.
These are fantastic results from a home router.
for those who want to use Gargoyle, they can use: flow offloading, hardware flow offloading and packet steering via ssh, you can find all the information here with the tests done!
DD-WRT has no AX Routers…And the developer Brainslayer doesn’t seem to have any interest in making DD-WRT work on any new routers…Basically for DD-WRT you’re using old AC routers or a x86 Box. I left DD-WRT about four years ago…It’s kind of a relic of the past.
