SIM card not registered on GL-MIFI-695

Marck · July 27, 2020, 4:12pm

Hi, I have a problem with GL-MIFI-695. On modem section shows “SIM card not registered”. I double-checked the SIM and is correct.

Any idea?

Here is the log.

Mon Jul 27 17:44:52 2020 daemon.err gl_monitor[3200]: killall: gcom: no process killed
Mon Jul 27 17:44:52 2020 daemon.info pppd[10038]: Terminating on signal 15
Mon Jul 27 17:44:52 2020 daemon.notice pppd[10038]: Connection terminated.
Mon Jul 27 17:44:53 2020 daemon.err gl_monitor[3200]: killall: uqmi: no process killed
Mon Jul 27 17:44:53 2020 daemon.info pppd[10038]: Exit.
Mon Jul 27 17:44:53 2020 daemon.notice netifd: Interface 'modem_1_1_2' is now down
Mon Jul 27 17:44:53 2020 daemon.notice netifd: Interface 'modem_1_1_2' is setting up now
Mon Jul 27 17:44:53 2020 user.notice root: modem_1_1_2 interface miss
Mon Jul 27 17:44:55 2020 user.debug : devices=null
Mon Jul 27 17:44:57 2020 daemon.notice netifd: modem_1_1_2 (11550): SIM ready
Mon Jul 27 17:44:57 2020 daemon.notice netifd: modem_1_1_2 (11550): PIN set successfully
Mon Jul 27 17:44:57 2020 daemon.notice netifd: modem_1_1_2 (11550): cat: can't open '/tmp/modem.1-1.2/signal': No such file or directory
Mon Jul 27 17:44:58 2020 daemon.notice pppd[11655]: pppd 2.4.7 started by root, uid 0
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: abort on (BUSY)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: abort on (NO CARRIER)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: abort on (ERROR)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: report (CONNECT)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: timeout set to 10 seconds
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: send (AT+CGDCONT=1,"IP","airtelwap.es"^M)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: timeout set to 30 seconds
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: expect (OK)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: ^M
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: OK
Mon Jul 27 17:44:59 2020 local2.info chat[11719]:  -- got it
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: send (ATD*99***1#^M)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: expect (CONNECT)
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: ^M
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: ^M
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: CONNECT
Mon Jul 27 17:44:59 2020 local2.info chat[11719]:  -- got it
Mon Jul 27 17:44:59 2020 local2.info chat[11719]: send ( ^M)
Mon Jul 27 17:44:59 2020 daemon.info pppd[11655]: Serial connection established.
Mon Jul 27 17:44:59 2020 kern.info kernel: [  398.914936] 3g-modem_1_1_2: renamed from ppp0
Mon Jul 27 17:44:59 2020 daemon.info pppd[11655]: Using interface 3g-modem_1_1_2
Mon Jul 27 17:44:59 2020 daemon.notice pppd[11655]: Connect: 3g-modem_1_1_2 <--> /dev/ttyUSB3
Mon Jul 27 17:45:00 2020 user.debug : devices=null
Mon Jul 27 17:45:05 2020 user.debug : devices=null
Mon Jul 27 17:51:38 2020 daemon.info pppd[11655]: System time change detected.
Mon Jul 27 17:51:41 2020 user.debug : devices=null
Mon Jul 27 17:51:46 2020 user.debug : devices=null
Mon Jul 27 17:51:51 2020 user.debug : devices=null
Mon Jul 27 17:51:56 2020 user.debug : devices=null
Mon Jul 27 17:52:01 2020 user.debug : devices=null
Mon Jul 27 17:52:02 2020 daemon.warn pppd[11655]: IPV6CP: timeout sending Config-Requests
Mon Jul 27 17:52:06 2020 user.debug : devices=null
Mon Jul 27 17:52:11 2020 user.debug : devices=null
Mon Jul 27 17:52:16 2020 user.debug : devices=null
Mon Jul 27 17:52:21 2020 user.debug : devices=null
Mon Jul 27 17:52:26 2020 user.debug : devices=null
Mon Jul 27 17:52:28 2020 daemon.err gl_monitor[3200]: killall: gcom: no process killed
Mon Jul 27 17:52:28 2020 daemon.info pppd[11655]: Terminating on signal 15
Mon Jul 27 17:52:28 2020 daemon.notice pppd[11655]: Connection terminated.
Mon Jul 27 17:52:29 2020 daemon.err gl_monitor[3200]: killall: uqmi: no process killed
Mon Jul 27 17:52:29 2020 daemon.info pppd[11655]: Exit.
Mon Jul 27 17:52:29 2020 daemon.notice netifd: Interface 'modem_1_1_2' is now down
Mon Jul 27 17:52:29 2020 daemon.notice netifd: Interface 'modem_1_1_2' is setting up now
Mon Jul 27 17:52:29 2020 user.notice root: modem_1_1_2 interface miss
Mon Jul 27 17:52:31 2020 user.debug : devices=null
Mon Jul 27 17:52:33 2020 daemon.notice netifd: modem_1_1_2 (13168): SIM ready
Mon Jul 27 17:52:33 2020 daemon.notice netifd: modem_1_1_2 (13168): PIN set successfully
Mon Jul 27 17:52:33 2020 daemon.notice netifd: modem_1_1_2 (13168): cat: can't open '/tmp/modem.1-1.2/signal': No such file or directory
Mon Jul 27 17:52:33 2020 daemon.notice pppd[13337]: pppd 2.4.7 started by root, uid 0
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: abort on (BUSY)
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: abort on (NO CARRIER)
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: abort on (ERROR)
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: report (CONNECT)
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: timeout set to 10 seconds
Mon Jul 27 17:52:34 2020 local2.info chat[13338]: send (AT+CGDCONT=1,"IP","airtelwap.es"^M)
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: timeout set to 30 seconds
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: expect (OK)
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: ^M
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: OK
Mon Jul 27 17:52:35 2020 local2.info chat[13338]:  -- got it
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: send (ATD*99***1#^M)
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: expect (CONNECT)
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: ^M
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: ^M
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: CONNECT
Mon Jul 27 17:52:35 2020 local2.info chat[13338]:  -- got it
Mon Jul 27 17:52:35 2020 local2.info chat[13338]: send ( ^M)
Mon Jul 27 17:52:35 2020 daemon.info pppd[13337]: Serial connection established.
Mon Jul 27 17:52:35 2020 kern.info kernel: [  463.676691] 3g-modem_1_1_2: renamed from ppp0
Mon Jul 27 17:52:35 2020 daemon.info pppd[13337]: Using interface 3g-modem_1_1_2
Mon Jul 27 17:52:35 2020 daemon.notice pppd[13337]: Connect: 3g-modem_1_1_2 <--> /dev/ttyUSB3

Marck · July 27, 2020, 4:30pm

Well I tryed another SIM card and now works. The problem is with Vodafone…

Any idea why does not work with Vodafone SIMs?

alzhao · July 28, 2020, 9:35am

Does you SIM need pin? If need pin, the UI will not be able to detect carrier info. So it will display not registered.

So you may need to input your correct pin to connect.

Marck · July 28, 2020, 10:11am

It needs PIN, is set and recognised…

Mon Jul 27 17:44:57 2020 daemon.notice netifd: modem_1_1_2 (11550): SIM ready
Mon Jul 27 17:44:57 2020 daemon.notice netifd: modem_1_1_2 (11550): PIN set successfully

The router connects because it’s able to retreive APNs… anyways I’ll remove the PIN to check…

Jorn · August 27, 2020, 8:33pm

I’m not sure if the 4 card is the same in x750 Spitz(EP06-E), but with that device I’m also having the same problems.
Dutch Vodafone simcard(no pincode, no prepaid card) is working perfectly in mobile phone, but in my router it only gives the message “SIM card not registered”

alzhao · August 28, 2020, 5:13am
