Unable to send SMS on GL-X3000

[NeByr]

My GL-X3000 router doesnt seem to be able to send SMS messages. It recieves them fine and the cellular connection works perfectly. But when i try to send messages i get a spinning timer and then just a red warning symbol. My firmware version is 0600snapshot1 and the carrier is Vodafone Ireland. Any recommended debugging steps would be appreciated

Thanks in advance!

[SpitzAX3000]

Maybe you need to fix the mms settings.

[NeByr]

Thanks for the quick response @SpitzAX3000

I dont see any MMS settings. Is there any guides you could point me to.

Thanks

[EricG]

NeByr,

I’m curious, why are you trying to send an SMS from the sim card in your router? Wouldn’t your phone be eaiser?

Eric

[NeByr]

Yes @EricG but it’s more for pay as you go comms with the carrier such as balance enquiries, top ups and low credit warnings.

[SpitzAX3000]

If you insert the sim in your phone can you send sms ? Is the sms call center number set correctly ?

[NeByr]

Yeah works fine from my mobile phone. I’ve tried many variations of multiple phone numbers. I’m struggling to find any error messages in the log

[ywp]

AT+CPMS?
AT+CGDCONT?
AT+CGPADDR
Can you run this command to see

[NeByr]

AT+CPMS replies ERROR

AT+CGDCONT replies OK

AT+CGPADDR replies…
+CGPADDR: 1,“10.143.202.147”
+CGPADDR: 2,“10.195.163.9”
+CGPADDR: 3,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”
+CGPADDR: 4,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”
+CGPADDR: 5,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”
OK

[SpitzAX3000]

@NeByr

AT+CPMS replies ERROR

This is the issue! It should return like this;

+CPMS: “ME”,0,255,“ME”,0,255,“ME”,0,255

OK

Try to fix it:

AT+CPMS=“ME”,“ME”,“ME”

@ywp thanks for hints!!

[NeByr]

Sorry I messed up, I have been educating myself on these commands and only see now that the first 2 you suggested were AT commands with a question mark. The last outputs I sent in the previous message were without the quesiton marks. The correct response should have been

AT+CPMS?
+CPMS: “ME”,0,255,“ME”,0,255,“ME”,0,255

AT+CGDCONT?
+CGDCONT: 1,“IPV4V6”,“live.vodafone.com”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”,0,0,0,0,“”,0
+CGDCONT: 2,“IPV4V6”,“ims”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”,0,0,0,0,“”,0
+CGDCONT: 3,“IPV4V6”,“hos”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”,0,0,0,0,“”,0
+CGDCONT: 4,“IPV4V6”,“sos”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”,0,0,0,1,“”,0
+CGDCONT: 5,“IPV4V6”,“web.vodafone.de”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”,0,0,0,0,“”,0

AT+CGPADDR
+CGPADDR: 1,“10.143.202.147”
+CGPADDR: 2,“10.195.163.9”
+CGPADDR: 3,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”
+CGPADDR: 4,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”
+CGPADDR: 5,“0.0.0.0”,“0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0”

So I think the prefferred message storage looks ok.

[SpitzAX3000]

@NeByr

So I think the prefferred message storage looks ok

Yes it look ok. Can you try to send sms again and check the logs for any errors ?

[NeByr]

Heres the recent log around the time I sent a test message. I have removed some repetative lines for brevity. I notice theres a line mentioning an error referencing sending the message.

Tue Apr 23 16:50:34 2024 kern.notice kernel: [1994090.588498] 7981@C08L3,ap_peer_auth_req_at_idle_action() 717: AUTH - MBSS(0), Rcv AUTH seq#1, Alg=0, Status=0 from [wcid=2]4c:55:cc:1b:45:ce
Tue Apr 23 16:50:34 2024 kern.notice kernel: [1994090.606430] 7981@C08L3,ap_cmm_peer_assoc_req_action() 1647: Recv Assoc from STA - 4c:55:cc:1b:45:ce
Tue Apr 23 16:50:34 2024 kern.notice kernel: [1994090.615891] 7981@C08L3,ap_cmm_peer_assoc_req_action() 2170: ASSOC Send ASSOC response (Status=0)…
Tue Apr 23 16:50:34 2024 kern.notice kernel: [1994090.625138] 7981@C01L3,wifi_sys_conn_act() 1115: wdev idx = 0
Tue Apr 23 16:50:34 2024 kern.notice kernel: [1994090.631743] 7981@C08L3,hw_ctrl_flow_v2_connt_act() 215: wdev_idx=0
Tue Apr 23 16:50:35 2024 kern.notice kernel: [1994090.746410] 7981@C15L3,WPABuildPairMsg1() 5280: <=== send Msg1 of 4-way
Tue Apr 23 16:50:35 2024 kern.notice kernel: [1994090.753258] 7981@C15L3,PeerPairMsg2Action() 6202: ===>Receive msg 2
Tue Apr 23 16:50:35 2024 kern.notice kernel: [1994090.760286] 7981@C15L3,WPABuildPairMsg3() 5557: <=== send Msg3 of 4-way
Tue Apr 23 16:50:35 2024 kern.notice kernel: [1994090.767083] 7981@C15L3,PeerPairMsg4Action() 6632: ===>Receive msg 4
Tue Apr 23 16:50:35 2024 kern.warn kernel: [1994090.779127] 7981@C15L2,PeerPairMsg4Action() 6994: AP SETKEYS DONE(ra0) - AKMMap=WPA2PSK, PairwiseCipher=AES, GroupCipher=AES, wcid=2 from 4c:55:cc:1b:45:ce
Tue Apr 23 16:50:35 2024 kern.warn kernel: [1994090.779127]
Tue Apr 23 16:50:39 2024 daemon.info dnsmasq-dhcp[4204]: DHCPDISCOVER(br-lan) 4c:55:cc:1b:45:ce
Tue Apr 23 16:50:39 2024 daemon.info dnsmasq-dhcp[4204]: DHCPOFFER(br-lan) 192.168.8.103 4c:55:cc:1b:45:ce
Tue Apr 23 16:50:39 2024 daemon.info dnsmasq-dhcp[4204]: DHCPREQUEST(br-lan) 192.168.8.103 4c:55:cc:1b:45:ce
Tue Apr 23 16:50:39 2024 daemon.info dnsmasq-dhcp[4204]: DHCPACK(br-lan) 192.168.8.103 4c:55:cc:1b:45:ce HubController-5CE
Tue Apr 23 16:51:10 2024 daemon.err modem_AT: (modem_AT.c:350) send_msg: AT+CMGS=18,0011000C915383672952470000FF04D4F29C0E
; len = 41
Tue Apr 23 16:52:34 2024 daemon.info eco[2321]: (gl-ngx-session:459) del ws
Tue Apr 23 16:52:35 2024 daemon.info eco[2321]: (gl-ngx-session:454) new ws
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:48:37:510] try to requestSetupDataCall 60 second later
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:49:37:572] requestSetupDataCall QMUXResult = 0x1, QMUXError = 0xe
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:49:37:572] call_end_reason is 1
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:49:37:572] call_end_reason_type is 2
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:49:37:573] call_end_reason_verbose is 210
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:49:37:573] try to requestSetupDataCall 60 second later
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:50:37:637] requestSetupDataCall QMUXResult = 0x1, QMUXError = 0xe
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:50:37:637] call_end_reason is 1
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:50:37:637] call_end_reason_type is 2
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:50:37:637] call_end_reason_verbose is 210
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:50:37:637] try to requestSetupDataCall 60 second later
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:51:37:703] requestSetupDataCall QMUXResult = 0x1, QMUXError = 0xe
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:51:37:703] call_end_reason is 1
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:51:37:703] call_end_reason_type is 2
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:51:37:703] call_end_reason_verbose is 210
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:51:37:704] try to requestSetupDataCall 60 second later
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:52:37:773] requestSetupDataCall QMUXResult = 0x1, QMUXError = 0xe
Tue Apr 23 16:52:37 2024 daemon.notice netifd: modem_0001 (27957): [04-23_16:52:37:773] call_end_reason is 1
Tue Apr 23 16:52:37 2024 daemon.info eco[2321]: (gl-ngx-session:459) del ws
Tue Apr 23 16:52:38 2024 daemon.info eco[2321]: (gl-ngx-session:454) new ws

[SpitzAX3000]

On my device it works out of the box. Have you tried to flash the device with the latest firmware version without keeping the old settings ?

BTW, to which phone number are you trying to send ? Same isp or different ?

Can you share your sms send screenshot before hitting the send please?

[ywp]

hello

Need help getting SMS to work

I am using a T-Mobile Magenta Max SIM. I did receive text messages when I first turned the Puli AX on the first time, and then again when I updated the firmware. Like something in booting up and connecting the first time triggered fetching SMS, but then it stopped working. I can’t send or receive. I am only connecting to 5G bands and I have ipv6 enabled. I’m not sure what is and isn’t relevant… Are there any settings or commands I should look at? Device: Puli AX Firmware version: 4.4.8 Modem f…

Can you refer to this post to try something out?
