Randomly stuck on "connecting" to Flint 2 WireGuard server - need help diagnosing

Routers VPN, DNS, Leaks
1

Hi guys.

I have a Flint 2 Home VPN server that randomly isn't working anymore. I have been vpn'd in for the last 3 months but now I can't connect to it. I restarted two separate client routers that have it's profile, tried a new profile too. Rebooted the home server router too and still nothing. As a hail mary we factory reset the flint 2 and set it up the same way and still nothing.

I have redundancy set up with another Flint 2 elsewhere and that is working so I know it is not my client router's issue.

Hardware:

  • Server: GL.iNet Flint 2
  • Client: GL.iNet Beryl AX
  • ISP: Spectrum (for Flint 2)

Setup:

  • Flint 2 connected via ethernet to Spectrum router
  • WireGuard server running on Flint 2: port 51825(I heard 51825 sometimes is buggy with spectrum, besides 51820 was not working either) IPv4 10.0.0.1/24
  • DDNS is enabled on Flint 2

Problem:

  • Beryl AX shows persistent yellow "connecting" status

Logs:

Wed May 21 22:12:27 2025 user.notice firewall: Reloading firewall due to ifdown of wgclient () Wed May 21 22:14:18 2025 user.notice wireguard-debug: USER=root ifname=wgclient ACTION=REKEY-GIVEUP SHLVL=1 HOME=/ HOTPLUG_TYPE=wireguard LOGNAME=root DEVICENAME= TERM=linux SUBSYSTEM=wireguard PATH=/usr/sbin:/usr/bin:/sbin:/bin PWD=/ Wed May 21 22:14:18 2025 daemon.notice netifd: Interface 'wgclient' is now down Wed May 21 22:14:18 2025 daemon.notice netifd: Interface 'wgclient' is setting up now Wed May 21 22:14:19 2025 user.notice firewall: Reloading firewall due to ifdown of wgclient () Wed May 21 22:16:09 2025 user.notice wireguard-debug: USER=root ifname=wgclient ACTION=REKEY-GIVEUP SHLVL=1 HOME=/ HOTPLUG_TYPE=wireguard LOGNAME=root DEVICENAME= TERM=linux SUBSYSTEM=wireguard PATH=/usr/sbin:/usr/bin:/sbin:/bin PWD=/ Wed May 21 22:16:10 2025 daemon.notice netifd: Interface 'wgclient' is now down Wed May 21 22:16:10 2025 daemon.notice netifd: Interface 'wgclient' is setting up now Wed May 21 22:16:10 2025 user.notice firewall: Reloading firewall due to ifdown of wgclient ()

Has anyone successfully set up GL.iNet router-to-router WireGuard through Spectrum? Any specific configuration tips or common pitfalls I should check?

Thanks for any guidance!

2

Use ``` on the lines before & after to post logs/code

like this
3

WTF are they doing to you guys over there?! Do you happen to know if Spectrum uses or recently switched to CG-NAT? Even if it's not CG-NAT I'd really reconsider WG given the ISP nonsense. Tailscale, AstroWarp, NetBird would take all that bollocks out of the equation for you.

(Be aware those SDNs aren't post-quantum cipher based should that matter to you but neither is WG without ensuring a PSK in its per-file conf)

4

Hi,

Please check if your modem/ router WAN IP is the public IP

5

That's a good point. Do you suspect the DDNS proc failed to update the endpoint?

@bananagod12
Once you get this all resolved, get this executed on your Beryl AX:

if [ ! "$(grep -m 1 '0 * * * * /usr/bin/wireguard_watchdog' /etc/crontabs/root)" = '0 * * * * /usr/bin/wireguard_watchdog     # hourly' ]; then
	printf '%s\n' '0 * * * * /usr/bin/wireguard_watchdog     # hourly' >> /etc/crontabs/root
fi
/etc/init.d/cron restart
[ "$(grep -m 1 'crontabs' /etc/sysupgrade.conf)" = '/etc/crontabs/ ] || printf '%s\n' '/etc/crontabs/' >> /etc/sysupgrade.conf

It'll check for & update your Beryl AX if your Flint v2's DDNS/IP updates on that remote endpoint/server.

6

I will check this today!

7

Oh nice! Let me see if I can still get WG to work, if not I can test out some of these solutions

1 Like
8

Also I made a typo, I have the flint 2 connected to the spectrum MODEM itself, no spectrum router is involved in this setup

9

Yeah, IDK, man... if Spectrum is playing games with your ports as you describe you might be far better served with a SDN/tailnet & get off the ISP wires as much as possible. Fawk'em!

10

@bruce I just checked, they both match :confused:

11

Please following these guides to check again:
